CDF/QT THICK-FILM | SBQ sensitized thick films 100µ up to 400µ

Intended for printing with plastisol inks on t-shirts and imprinted sportswear items. Extremely fast exposure times make the QT series suited for use with low power light sources. SBQ sensitized, pink colored films available in 100, 150, 200, 250, 300 and 400µ thicknesses. Adherable with water or QTX® emulsion.

CDF/QT Thick-Film is ideal for the production of thick stencils for specialty printing needs, including high density, puff, and lenticular effects for imprinted sportswear; peelable solder masks in the electronics industry; false mosaic and leading effects for glass and ceramic decorating; screen printed gaskets and seals; and many other manufacturing and decorating applications requiring ultra-thick ink deposits with non-aggressive solvent inks and pastes.

CDF/QT Thick-Film is a precisely coated, capillary film version of Ulano’s best-selling QTX® direct emulsion. Like QTX, CDF/QT Thick-Film utilizes pure photopolymer (SBQ) technology to assure extended shelf life and minimal influences from heat and humidity, the fastest possible exposure speed, good imaging properties, and on-press durability. Generally, CDF/QT Thick-Film is adhered to fabric with QTX using the direct/indirect application technique. CDF/QT Thick-Films can be laminated to produce unlimited stencil thickness variations.

The use of CDF/QT Thick-Film offers significant savings in labor and production time over the use of direct emulsion to produce stencils of similar thicknesses.



FEATURES

BENEFITS

Consistent stencil thickness -Control of ink deposit—and ink costs

Control of ink deposit—and ink costs


High contrast/transparent pink color -Easy inspection and registration

Easy inspection and registration


“Pre-coated” stencils -No mess or waste

No mess or waste


Available in your size custom-cut sheets

Speeds production




FORMATS

AVAILABILITY Rolls

  • CDF/QT30 CDF/QT3026300 26"x300"

  • CDF/QT50 CDF/QT5026300 26"x300"

  • Larger rolls available upon request

AVAILABILITY in sheets (they're thick, they don't roll)

  • Thicknesses of 30, 50, 100, 150, 200, 250, 300, 400 microns

  • Custom-cut sheets (minimum order: 25 sheets of any one size and thickness)

Packages of mostly 10 Pre-Cut Sheets

  • CDF/QT-200
    PCDFQT200810-X 8"x10"
    PCDFQT2001414-X 14"x14"

  • CDF/QT-250
    PCDFQT250810-X 8"x10"
    PCDFQT2501414-X 14"x14"

  • CDF/QT-300
    PCDFQT300810-X 8"x10"
    PCDFQT3001414-X 14"x14"
    CDFQT3001414-2 14" × 14" 2 test sheets

  • CDF/QT-400
    PCDFQT400810-X 8"x10"
    PCDFQT4001414-X 14"x14"
    CDFQT4002026-5 20" × 26" 5 test sheets

  • CDF/QT-30 50 sheets
    PCDF/QT301414 14"x14"
    PCDF/QT301618 16"x18"

  • CDF/QT-50 50 sheets
    PCDF/QT501414 14"x14"
    PCDF/QT501618 16"x18"

  • CDF/QT-100
    PCDFQT100810-X 8"x10"
    PCDFQT1001414-X 14"x14"

  • CDF/QT-150
    PCDFQT150810-X 8"x10"
    PCDFQT1501414-X 14"x14"
